Product Summary

The MN3007 is a 1024-stage long delay low noise BBD that provides a signal delay of up to 51.2msec. The device is particulary suitable for use as reverberation effect of electronic musical instrument such as stereo eqipment due to its long delay times.

Parametrics

MN3007 absolute maximum ratings: (1)terminal voltage, VDD, VGG, VCP, VI: -18 to 0.3V; (2)output voltage, VO: -18 to 0.3V; (3)operating temperature, Tstg: -5 to 125℃.

Features

MN3007 features: (1)variable delay time of audio signal; (2)clock component cancellation capability; (3)no insertion loss; (4)wide dynamic range; (5)wide requency response; (6)low distortion; (7)clock frequency range: 10 to 100KHz; (8)P channel silicon gate process; (9)8-lead dual-in-line plastic package.

Diagrams

MN3007 block diagram
