S1D13806F00A100

LCD Controller IC, QFP144, –0.3 to 7.0V, 8 ×16 pixel characters, 3.5 mA operating current

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~10.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~10.00

PartNumber:: S1D13806F00A100

Brand:: Epson Company - EPSON | Pack: QFP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. tiffany's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-11-02

From Other Seller

Part Number:S1D13806F00A100
US $1.00 - 10.00
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
HEF4093BT

US $0.15 - 1.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The S1D13806F00A100 is a controller IC that can display text and graphics on LCD panel. The S1D13806F00A100 can display layered text and graphics, scroll the display in any direction and partition the display into multiple screens. The S1D13806F00A100 stores text, character codes and bitmapped graphics data in external frame buffer memory. Display controller functions include transferring data from the controlling microprocessor to the buffer memory, reading memory data, converting data to display pixels and generating timing signals for the buffer memory, LCD panel.

Parametrics

S1D13806F00A100 absolute maximum ratings: (1)Supply voltage range: –0.3 to 7.0V; (2)Input voltage range: –0.3 to VDD + 0.3 V; (3)Power dissipation: 300 mW; (4)Operating temperature range: –20 to 75 ℃; (5)Storage temperature range: –65 to 150 ℃; (6)Soldering temperature (10 seconds). See note 1: 260℃.

Features

S1D13806F00A100 features: (1)Text, graphics and combined text/graphics display modes; (2)Three overlapping screens in graphics mode; (3)Up to 640 ×256 pixel LCD panel display resolution; (4)Programmable cursor control; (5)Smooth horizontal and vertical scrolling of all or part of the display; (6)1/2-duty to 1/256-duty LCD drive; (7)Up to 640×256 pixel LCD panel display resolution memory; (8)160, 5 ×7 pixel characters in internal mask programmed character generator ROM; (9)Up to 64, 8 ×16 pixel characters in external character generator RAM; (10)Up to 256, 8 ×16 pixel characters in external character generator ROM; (11)6800 and 8080 family microprocessor interfaces; (12)Low power consumption-3.5 mA operating current.
