UF4002

UF4002, 1A, 100V, plastic rectifier, DO-41, Vishay Siliconix

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.01~100.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.01~100.00

PartNumber:: UF4002

Brand:: Vishay Siliconix - vishay | Pack: DO | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. tiffany's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-09

From Other Seller

Part Number:UF4002
US $0.01 - 100.00
HEF4051BT

US $0.15 - 1.20 / Piece
(0) Remove
AT24C02BN-SH-T

US $0.08 - 0.15 / Piece
(0) Remove
Quantity:

piece

Product Summary

The UF4002 is an ultrafast efficient plastic rectifier.

Parametrics

UF4002 absolute maximum ratings: (1)Maximum repetitive peak reverse voltage, VRRM: 100Volts; (2)Maximum RMS voltage, VRMS: 70Volts; (3)Maximum DC blocking voltage, VDC: 100Volts; (4)Maximum average forward rectified current 0.375" (9.5mm) lead length at TA=55℃, I(AV): 1.0 Amp; (5)Peak forward surge current 8.3ms single half sine-wave superimposed on rated load (JEDEC Method), IFSM: 30.0 Amps; (6)Maximum instantaneous forward voltage at 1.0A, VF: 1.0Volts; (7)Maximum DC reverse current at rated DC blocking voltage, TA=25℃, IR: 10.0μA; TA=100℃, IR: 50.0 μA; (8)Maximum reverse recovery time, trr: 50.0ns; (9)Typical junction capacitance, CJ: 17.0 pF; (10)Typical thermal resistance, RQJA: 60.0℃/W; RQJL: 15.0 ℃/W; (11)Operating junction and storage temperature range, TJ, TSTG: -55 to +150℃.

Features

UF4002 features: (1)Plastic package has Underwriters Laboratory Flammability Classification 94V-0; (2)1.0 ampere operation at TA=55℃ with no thermal runaway; (3)Glass passivated chip junction; (4)Low cost; (5)Ultrafast recovery time for high efficiency; (6)Low forward voltage; (7)Low leakage current; (8)High surge current capability; (9)High temperature soldering guaranteed: 250℃/10 seconds, 0.375" (9.5mm) lead length, 5 lbs. (2.3kg) tension.
